T7 Mini32 V1.5
LILYGO® TTGO T7 Mini32 V1.5 ESP32 Dual Core PSRAM Wireless Wi-Fi Bluetooth Module Development Circuit Board CH9102
Specifications
Hardware |
|
| Chipset |
ESP32 240MHz Xtensa⑧single-/dual-core 32- bit LX6 microprocessor |
| FLASH | QSPI flash 4MB 16MB / PSRAM 8MB |
| SRAM | 520 kB SRAM |
| USB serial port chip | CH9102 |
| Button | reset |
| Modular interface |
UART、SPI、 SDIO、 I2C、 LED PWM、TV PWM、I2S、 IRGPIO、 ADC、DACLNA pre-amplifier |
| On-board clock | 40MHz crystal oscillator |
| Working voltage | 2.7V-3.6V |
| Working current | About 30mA |
| Working temperature range | -40°C ~ +85°C |
| Size&weight | 40.27*31.07*8.13mm (6.42g) |
| Power Supply |
Micro USB 5V/1A Jst 2pin 1.25mm |
| Wi-Fi Frequency range |
2.4GHz~2.5GHz |
|
Bluetooth Protocol |
Meet Bluetooth |
Software |
|
| Wi-Fi Mode | Station/SoftAP/SoftAP+ Station/P2P |
| Security mechanism | WPAWPA2/WPA2-Enterprise/WPS |
| Encryption Type | AES/RSA/ECC/SHA |
| Firmware upgrade | UART download/OTA (Through network/host to download and write firmware) |
| Software Development | Support cloud server development /SDK for user firmware development |
| Networking protocol | IPv4、IPv6、 SSL、 TCP/UDP/HTTP/FTP/MQTT |
| User Configuration | AT + Instruction set, cloud server, android/iOSapp |
| OS | FreeRTOS |
Technology Support [Github]
If you need technical support please check the link to find more details.
T7 Mini32 V1.5 Introduce
Note: The difference between T7 V1.4 changed to V1.5:
GPIO has replaced the position, we replaced GPIO16 and GPIO17 two pins that can no longer be used for external expansion with GPIO25 and GPIO27 that can be used with defined functions, so that they can be compatible with those of miniD1 The expansion board is not affected by the original GPIO16 and GPIO17 pins.
1. Size
2. Pin Diagram
T7 Mini32 V1.5 Options
- 1 X T7 Mini32 (4/16MB)
- 6 X Pin
- 1 X line
