T-FPGA
The circuit board is an integrated ESP32S3 and FPGA (GW1NSR-LV4CQN48PC6/I5) control chip. With the power management AXP2101 can be used to switch the voltage of different BANK areas. And there are as many as 6 data lines for communication between FPGA and MCU.
We are looking forward to you injecting your inspiration into this board with endless potential!
Specifications
| MCU | ESP32-S3R8 Dual-core LX7 microprocessor |
| Wireless Connectivity | 2.4 GHz Wi-Fi & Bluetooth5 (LE) |
| Development | Arduino, Platforml0-IDE, Micropython |
| Flash | 16MB |
| PSRAM | 8MB |
| Antenna | Ceramic (Default) |
| Onboard functions | Boot + Reset + Power Button |
| FPGA Chip | GW1NSR-LV4CQN48PC6/15 |
| Device | GW1NSR-4C |
| Package | QFN48P |
| Speed | C6/15 |
| LUT4 | 4608 |
| Flash | 256K |
| HyperRAM | 64Mb |
| Hardcore processor | Cortex-M3 |
| Development | Development |
| Designer Debug port | JTAG |
Sample Code For Reference [Github]
